RH Semi-automatic Spring Coiling Machine

The machine is mainly used for coiling double- cone spring for mattress.
  • square. sifang
RH Semi-automatic Spring Coiling Machine

Main application and performance:

The spring machine is mainly used for coiling the double-cone shaped springs of soft furnitures such as mattresses and sofas. The mattress machine(spring machine) is easy to be operated and adjusted and the springs made with it are stable in shape.

Product Specification:

Model RH1
Spring end diameter 45-90 mm  adjustable
Spring turns 4-8 turns
Spring height 80-200 mm
Applicable wire diameter 1.8-2.6 mm
Productivity 48, 64, 82 pcs/min
Motor power 1.1 kw
Motor power of paying off swift 0.37 kw
Overall dimensions 660 x 580 x 1150 mm


mattress machine certificate

CNC Machining Center:

mattress machine cnc machining center

Conventional Machine Center:
mattress machine conventional machine center




mattress machine exhibition

Mattress Brand we served:
QQ图片20151201081856 QQ图片20151201082047 QQ图片20151201081748 QQ图片20151201081908 QQ图片20151201081956 QQ图片20151201081928 QQ图片20151201081640
QQ图片20151201081811 QQ图片20151201081542 QQ图片20151201081800 QQ图片20151201081724 QQ图片20151201082009 QQ图片20151201081841 QQ图片20151201081657
QQ图片20151201081710 QQ图片20151201081825 QQ图片20151201082021 QQ图片20151201082505 QQ图片20151201082322 QQ图片20151201082515 QQ图片20151201082538
QQ图片20151201082310 QQ图片20151201082432 QQ图片20151201082644 QQ图片20151201082110 QQ图片20151201082421 QQ图片20151201082137 QQ图片20151201082344
QQ图片20151201082137 QQ图片20151201082744 QQ图片20151201082443 QQ图片20151201082632 QQ图片20151201082558 QQ图片20151201082213 QQ图片20151201082813

Machine Layout :

RH1 semi-automatic spring coiling machine layout size

The machine will be packed in two plywood wooden cases.

Package 1: 780x700x1350 mm

Total G.W.: 340 kgs
