SCH Automatic Assembling Machine

This machine is mainly used for assembling spring mattress core.

Quantity:
  • square. sifang
SCH Automatic Assembling Machine


Main application and performance:

This machine is an mainly used for assembling spring mattress core. Upper and lower spring are assembled simultanuously. Meanwhile, it also can tighten the helical wire at both ends automatically. The numbers of row can be counted automatically. When the cycle is concluded, the spring units are pushed out. The numbers of row can be set by computer. In this way, the production speed of spring unit can be raised.


Product Specification:

Assembling speed 60-80 unit/shift
Max. spring unit width 2000 mm
Diameter of helical wire 1.3-1.4 mm
Spring wire diameter 1.9-2.4 mm
Spring end diameter 70-90 mm
Spring height 80-180 mm
Total motor power 3.3 kw
Overall dimensions 3000 x 2100 x 1800 mm

Assembling speed 60-80 unit/shift
Max. spring unit width 2000 mm
Diameter of helical wire 1.3-1.4 mm
Spring wire diameter 1.9-2.4 mm
Spring end diameter 70-90 mm
Spring height 80-180 mm
Total motor power 3.3 kw
Overall dimensions 3000 x 2100 x 1800 mm
