The classic tape edge machine, it is an ideal equipment for mattress and cushions. with the walking & sewing speed adjustable, and the auto slow-down mechanism at the corner, the machine is easy to operate and can sew a very good mattress.
Semi-automatic high versatile tape edge mattress sewing machine
Main application and performance:
Model FB3C semi-automatic high versatile tape edge matress sewing machine can sew high range of mattresses, from 20mm thickness to 520mm thickness. It iss being supported by high-strength independent column. the mattress machine's working condition becomes more stable. An inside-hidden-power-supply column makes the tape edge machine have no special requirement on installation space.
1.The pillar plus cross-shaped support table firmly, raiser and lower table by four screw rods at each corner stable.
2 Sewing thickness range of mattress can be 20-520mm.
3.the walking speed and sewing speed of our tape edge machine is continuously adjustable by turning the knob on the working panel.
4.Auto slowdown at the corner.
5.the walking speed and sewing speed of our tape edge machine is continuously adjustable by turning the knob on the working panel.
|Sewing head type||Lock stitch/chain stitch|
|Corner speed auto slow down||Yes|
|Working angle of the sewing head||35-55 degaree|
|Sewing thickness range of mattress||20-520mm|
|Lifting of working table||Electric|
|Size of the working table||1600x2000mm,1800x2000mm|
|Sewing head speed||1100-3000 ( Select according to the type of sewing head)|
|Motor type||single, three-phase motor|
|Total Power||1.12KW |
